Flake Ice Evaporator Technical Parameters Sheet

No.

Model

Ice Maker Shape

Evaporator Specifications

Reducer

Water Pump

Circulating Water Tank

Overall Performance

OD Ø * H  mm

Ice Outlet Ø  mm

Power kW

Power kW

Feed Water

Inlet

Drain

Outlet

Production

Capacity

Weight

Cooling

Load

Rc PVC

PVC pipe

t/d

kg

kW

1

F050S

478*599

375

0.18

0.014

1×1/2"

1/2"

0.5

96

2.75

2

F075S

478*644

375

0.18

0.014

1×1/2"

1/2"

0.75

104

4.125

3

F10S

478*785

375

0.18

0.014

1×1/2"

1/2"

1

108

5.5

4

F12S

478*785

375

0.18

0.014

1×1/2"

1/2"

1.2

108

6.6

5

F16S

648*894

510

0.37

0.025

1×1/2"

1/2"

1.6

208

8.8

6

F20S

648*969

510

0.37

0.025

1×1/2"

1/2"

2

220

11

7

F25S

648*1029

510

0.37

0.025

1×1/2"

1/2"

2.5

230

13.75

8

F40S(A)①

648*1084

510

0.37

0.025

1×1/2"

1/2"

4

240

22

9

F60S(A)

920*1331

710

0.37

0.125

1×1/2"

3/4"

6

550

33

10

F80S(A)

1160*1586

920

0.55

0.25

1×3/4"

3/4"

8

830

44

11

F100S(A)

1160*1846

920

0.75

0.25

1×3/4"

3/4"

10

980

55

12

F150S(A)

1462*2080

1277

0.75

0.4

2×3/4"

1-1/4"

15

1690

82.5

13

F200S(A)

1600*2744

1420

1.1

0.4

2×3/4"

1-1/4"

20

2634

110

14

F250S(A)

1990*2887

1790

1.1

0.75

3×3/4"

1-1/4"

25

3588

137.5

15

F300S(A)

1990*3027

1790

1.1

0.75

3×3/4"

1-1/4"

30

3980

165

16

F350S(A)

2337*3071

2150

1.5

0.75

3×3/4"

1-1/4"

35

4500

192.5

17

F400S(A)

2337*3371

2150

1.5

0.75

3×3/4"

1-1/4"

40

5400

220

18

F600S(A)

2337*3787

2150

1.5

0.75

3×3/4"

1-1/4"

60

6700

330
